KTHC-B Series Side Sealing Plastic Bag Machine

This Side Sealing Plastic Bag Machine is suitable for making BOPP, OPP, POF, PE, etc printing and non-printing side sealing bags. Which wildly use for Office Stationery packing, such as pen, ruler, notebook, etc; electrical parts packing, bread packing, clothes packing, sock packing, etc

Features

  • With Microcomputer Control System
  • Material Feeding by Stepping Motor
  • With Length Control and Auto Counting System
  • With Photo Senor Checking System for Printing Mark
  • With Round Hole Puncher
  • With 2 type Different Sealing Knife
  • Optional: Inline Folding System
  • Optional: Tape Attached System
  • Optional: Double Production Line
CE Certification

Products Our Machine Can Make

Plastic Bag Machine
Plastic Bag Machine
Plastic Bag Machine
Plastic Bag Machine
Machine Specifications
Model KTHC-B 500 KTHC-B 600 KTHC-B 700
Material Width 480mm 580mm 680mm
Bag Width 40-700mm 40-700mm 50-700mm
Bag Length 480mm 580mm 680mm
Speed 40-260 pcs/min 40-260 pcs/min 40-260 pcs/min
Total Power 3.4 kw 3.5 kw 3.6 kw
Machine Weight 700 kg 750 kg 800 kg
Machine Size 3000 x 1000 x 1800mm 3000 x 1000 x 1800mm 3000 x 1100 x 1800mm

Model KTHC-B 800 KTHC-B 900 KTHC-B 1000
Material Width 780 mm 880 mm 950 mm
Bag Width 50-700 mm 60-900 mm 60-900 mm
Bag Length 780 mm 880 mm 980 mm
Speed 40-260 pcs/min 40-180 pcs/min 40-180 pcs/min
Total Power 3.8 kw 4.5 kw 4.7 kw
Machine Weight 850 kg 900 kg 950 kg
Machine Size (LWH) 3000 x 1200 x 1800mm 3000 x 1300 x 1800mm 3000 x 1400 x 1800mm

Model KTHC-B 1100 KTHC-B 1200 KTHC-B 1300
Material Width 1050 mm 1150 mm 1250 mm
Bag Width 60-900 mm 60-900 mm 60-900 mm
Bag Length 1050 mm 1150 mm 1250 mm
Speed 40-180 pcs/min 40-180 pcs/min 40-180 pcs/min
Total Power 5.2 kw 5.5 kw 5.7 kw
Machine Weight 1100 kg 1100 kg 1200 kg
Machine Size (LWH) 3000 x 1500 x 1800mm 3000 x 1600 x 1800mm 3000 x 1700 x 1800mm
