KTNW-M Series Fully Automatic Non Woven Bag Making Machine

This Fully Automatic Non Woven Bag Making Machine Is Suitable To Use Roll Non Woven Fabrics To Make D Cut Bags, T-Shirt Bags, Soft-Loop Handle Bags, Vice Box Bottom Bags Fully Automatic. It Is a High Efficient Bag Making Machine


  • With PLC touch Screen Control System
  • With Ultrasonic Sealing System
  • Material feeding Control by Step motor
  • Unwind with Auto Loading and EPC System
  • With Auto Length Control System
  • With Automatic Counting System
  • With Auto Temperature Control System
  • With Auto Photo Senor Checking System
  • D Cut Bag with Auto Banana Handle Punch System
  • T -shirt Bag with Auto W Cut and U Cut Punch system
  • With Auto Soft Loop Handle Attached System
  • Optional: Servo Motor Drive System
CE Certification
USD 42,000.00 - 48,000.00

Products Our Machine Can Make

Non Woven Bag Making Machine box bag
Non Woven Bag Making Machine d cut bag
Non Woven Bag Making Machine loop handle bag
Non Woven Bag Making Machine w cut bag
Machine Specifications
Model KTNW-M600 KTNW-M700
Raw Material PP Non-Woven Fabric

RPET Non-Woven Fabric

Finished Bag D Cutting Bag/T-Shirt Bag

Soft Loop Handle Bag/Vice Box Bag/Rope Bag

Max. Raw Material Width 1250mm (49.2”) 1450mm (57.1”)
Max. Raw Material Diameter Φ800mm (31.5″) Φ800mm (31.5″)
Material Thickness 30-120gsm (1.18”-4.72”) 30-120gsm (1.18”-4.72”)
Max. Bag Making Speed 120bags/min 100bags/min
D Cut Bag Width 100-800mm (3.9”-31.5”) 100-800mm (3.9”-31.5”)
D Cut Bag Height 200-580mm (7.9”-22.8”) 200-580mm (7.9”-22.8”)
D Cut Bag Top Gusset 40-80mm (1.7”-3.1”) 40-80mm (1.7”-3.1”)
D Cut Bag Bottom Gusset 100-200mm (3.9”-7.9”) 100-200mm (3.9”-7.9”)
D Cut Bag Hole Size 20x80mm (0.78”3.1”) 20x80mm (0.78”3.1”)
T-shirt Bag Width 200-450mm (7.9”-17.7”) 200-450mm (7.9”-17.7”)
T-shirt Bag Length 100-800mm (3.9”-31.5”) 100-800mm (3.9”-31.5”)
T-shirt Bag Side Gusset 100-200mm (3.9”-7.9”) 100-200mm (3.9”-7.9”)
Soft-loop Handle Width 25/28/30mm (0.98”/1.1”/1.18”) 25/28/30mm (0.98”/1.1”/1.18”)
Soft-loop Handle Length 380-580mm (15”-22.8”) 380-580mm (15”-22.8”)
Soft-loop Handle Spot Width 120-200mm (4.7”-7.9”) 120-200mm (4.7”-7.9”)
Box Bag Side & Bottom Gusset 50-75mm (1.97”-2.95”) 50-75mm (1.97”-2.95”)
Total Power 18kw 20kw
Machine Weight 4000kg 4500kg
Machine Size (LWH) 14000 x 2200 x 2100mm 14000 x 2200 x 2100mm
Power Support 3 Phase 220/380/440V 50/60HZ
