KTLP-S60D Series Inline 3 Die Cutting Flexo Label Printing Machine

This Flexo Label Printing Machine Includes Unwinding, Printing, Varnishing, Drying, Laminating, Die-Cutting, Rewinding, And Sheet Cutting, All These Functions Can Be Finished One Time by This Machine. It Is a Highly Efficient Machine For Printing Adhesive Labels.

Features

  • Use Ceramic Anilox Roller for Ink Transfer
  • Unwind and Rewind with Auto Tension Control
  • Unwind With EPC Controller
  • Unwind With Reverse Printing Turn Bar
  • Printing Unit Adopt 360° Plate Adjustment
  • Printing Unit Equipped with IR Dryer (Hot Air)
  • With Inline 3 Die Cutting Station
  • 1st and 2nd Die Cutting Roller Can Exchange for Double Side Work
  • 3rd Die Cutting Station Support Sheet Cutting.
  • Optional: UV Drying, Web Video Inspection,
  • Optional: Double Rewind, Sheeter Conveyer
CE Certification
USD 80,000.00 - 100,000.00

Products Our Machine Can Make

Flexo Label Printing Machine Samples
Flexo Label Printing Machine Samples
Flexo Label Printing Machine Samples
Flexo Label Printing Machine Samples
Machine Specifications
Model KTLP-S60D/ 320 KTLP-S60D/ 450
Raw Material Adhesive Label Adhesive Label
Printing Color 1-6 colors(4+4colors) 1-6 colors(4+4colors)
Max. Mechanical Speed 60m/min 60m/min
Max. Printing Speed 50m/min 50m/min
Max. Raw Material Width 320mm (12.6″) 460mm (18.1″)
Max. Printing Width 310mm (12.2″) 450mm (17.7″)
Max. Unwind Diameter Φ600mm (23.6″) Φ600mm (23.6″)
Max. Rewind Diameter Φ600mm (23.6″) Φ600mm (23.6″)
Printing Repeat Length 177.8-355.6mm (7-14”)

206.3-460.3mm (optional)

238.1-539.25mm (optional)

177.8-355.6mm (7-14”)

206.3-460.3mm (optional)

238.1-539.25mm (optional)

Rubber Plate Thickness 1.14mm or 1.7mm 1.14mm or 1.7mm
Color Register Precision ±0.10mm ±0.10mm
Machine Weight About 3350kg About 3550kg
Machine Dimension (LWH) 2600 x 1100 x 3050mm(6colors) 2600 x 1230 x 30500mm(6colors)
Power Support 3 Phase 220/380/440V 50/60HZ 3 Phase 220/380/440V 50/60HZ
