KTLM-SB180 Series High Speed Dry Laminating Machine

This High Speed Dry Laminating Machine Is Suitable For Laminating Different Kinds Of Materials In The Packing Industry Such As Plastic-Plastic, Paper-Plastic, And Aluminum-Plastic Lamination.

Features

With PLC touch screen system
Double Frequency Conversing Synchronic
Two Means of Glue Applying
Top Air Style Oven Open, Initiative Guiding Roll in Oven
4-sect Heating in Drying Oven Separate Control
Photoelectric Error Correction for Rewind
Reeling and Unreeling by Tumbling Dual-station Mechanism
Oil Warming System for Composite Reel
Optional: 4 Motor or 8 Motor Tension Control System

Send Enquiry

Machine Specifications

Model	KTLM-SB180
Raw Material Width	1050/1250/1350mm (41.3”/49.2”/53.2”)
Raw Material	Plastic film, Paper, Aluminum Foil
Laminating Stratification	2Layers
Glue	Solvent Based
Max. Mechanical Speed	180 m/min
Max. Laminating Speed	150m/min
Unwind and Rewind Diameter	Φ600/Φ800mm (23.6”/31.2”)
Paper Core Inner Diameter	Φ76mm (3”)
Oven Temperature	80℃
Total Power	95kw
Machine Weight	10000kg
Machine Size (LWH)	12600×3600×3300mm
Power Support	5Lines 3 Phase 220/380/440V 50/60HZ
