CI Flexo Printing Machine Manufacturer

विशेषता	सीआई फ्लेक्सो प्रेस	Stack Type Flexo Press	इनलाइन फ्लेक्सो प्रेस
Core Structure	Single, large central impression drum. All colors print against it.	Independent color stations stacked vertically. Each has its own impression cylinder.	Independent color stations arranged horizontally in a line. Each has its own impression cylinder.
Registration	Exceptional. The substrate is "locked" to the drum, eliminating misregistration.	Poor to Fair. Substrate "flutters" between stations. Not suitable for stretchable films.	Good. Better than Stack, but long web paths can cause tension issues on thin or wide materials.
Best For	High-end wide web flexo printing machine applications: flexible packaging (PE, BOPP, PET), laminates, high-quality graphics.	Double-sided printing (via turn bar). Paper bags, non-woven bags, wide paper rolls.	Narrow-web labels, folding cartons, tags. Excellent for adding many inline (die-cutting, cold foil) processes.
Key Advantage	High precision at high speed.	Small footprint. Low cost. Double-sided printing capability.	Extreme modularity. Can add unlimited stations.

विशेषता

सीआई फ्लेक्सो प्रेस

Stack Type Flexo Press

इनलाइन फ्लेक्सो प्रेस

Core Structure

Single, large central impression drum. All colors print against it.

Independent color stations stacked vertically. Each has its own impression cylinder.

Independent color stations arranged horizontally in a line. Each has its own impression cylinder.

Registration

Exceptional. The substrate is "locked" to the drum, eliminating misregistration.

Poor to Fair. Substrate "flutters" between stations. Not suitable for stretchable films.

Good. Better than Stack, but long web paths can cause tension issues on thin or wide materials.

Best For

High-end wide web flexo printing machine applications: flexible packaging (PE, BOPP, PET), laminates, high-quality graphics.

Double-sided printing (via turn bar). Paper bags, non-woven bags, wide paper rolls.

Narrow-web labels, folding cartons, tags. Excellent for adding many inline (die-cutting, cold foil) processes.

Key Advantage

High precision at high speed.

Small footprint. Low cost. Double-sided printing capability.

Extreme modularity. Can add unlimited stations.

सामान्य प्रश्न

1. We print a variety of products with different specifications. How can you help us determine which KETE press is the right fit for our current and future business needs?

Our process starts with your specific application, not a catalog. We analyze your primary substrates (especially flexible films vs. paper), required print width, and production speed goals. This helps us determine if a robust geared ci press (for value and reliability) or a high-speed gearless ci flexo printing press (for maximum automation and precision) is the right fit. We then configure the exact color stations and drying system to maximize your ROI, both today and for your future growth.

2. Our production requirements are quite unique. Do you offer custom configurations or optional add-ons if a standard machine doesn't quite fit what we need?

Absolutely. We are the manufacturer. For our central impression flexo press line, this means we routinely engineer custom solutions. Standard models are just the starting point. We can integrate inline slitting, a turn bar (for reverse printing), specialized video inspection systems, or unique corona treaters to create a ci flexo printing machine that perfectly matches your specific workflow. Let’s discuss your challenges, and we’ll design the solution.

3. We often struggle with issues like static on films and getting good ink adhesion on certain substrates. How do your presses help manage or solve these common printing headaches?

These are critical challenges, especially in ci flexo printing on films. Our ci flexo press is designed with a very short web path and superior web handling to manage static. For ink adhesion, our stable chambered doctor blade systems and high-efficiency dryers are key. However, the definitive solution is an optional Corona Treatment system, which we can seamlessly integrate to modify the substrate’s surface energy, guaranteeing a strong, permanent ink bond on any film.

4. What range of substrates can your presses handle? We work with everything from flexible films and paper to specialty label stock.

Our central drum flexo printing machine is engineered to master the most challenging substrates. Its primary strength, and the reason clients choose a ci press, is its unmatched ability to handle thin, stretchable flexible films (BOPP, PET, PE, CPP, laminates). As a versatile wide web flexo press, it also delivers excellent, high-quality results on paper, non-woven fabrics, and aluminum foil. The key is our advanced tension control system, which is optimized for these sensitive materials.

5. My clients demand high quality and consistent color on every job. What features do your machines have to ensure sharp printing and precise color registration, not just on the first run, but on repeat jobs as well?

This is the core advantage of a ci flexo printing machine. The substrate is “locked” to the massive central impression drum, which physically eliminates registration errors between colors, even on thin films. When this is combined with a Gearless Servo Drive (on our CIG models), you get rock-solid ±0.10mm accuracy at high speeds. For repeatability, our PLC Job Memory saves all parameters (tension, registration, pressure), so your repeat jobs run perfectly in under 10 minutes, every single time.

6. What are the facility requirements for installing one of your presses? We need to know what to prepare regarding foundation, power, and air supply before the machine arrives to ensure a smooth installation.

To ensure a smooth installation for your ci flexographic printing press, we provide a detailed pre-installation checklist well before the machine ships. This document outlines all requirements for the concrete foundation’s load-bearing capacity, the precise electrical power (KVA, voltage), and the necessary compressed air volume and pressure. Following this guide guarantees your facility is 100% ready for our engineers.

7. What kind of installation support and operator training is included with a new press? Will your technicians come to our facility to train our team?

Yes, on-site installation and training are fundamental to our service. KETE-certified engineers will travel to your facility to manage the complete commissioning and calibration of your ci flexo printing press. They then provide hands-on training for your team, focusing on efficient operation, rapid sleeve changeovers, preventative maintenance, and mastering the automated features of your new central impression flexo press.

8. Downtime is our biggest concern. If we need a spare part, how fast can we get it? Do you keep critical parts in stock to help get us back up and running quickly?

We understand that uptime is critical for a high speed flexo printing machine. We maintain a large inventory of critical ci flexo press parts, including anilox sleeves, servo motors, and doctor blades. For international clients, we use express air freight (DHL/FedEx) to dispatch parts immediately, getting your machine back online fast.

9. A new press is a major investment for us. How can we calculate the potential return on investment (ROI)? What key benefits should we consider to justify this purchase for our business?

The ROI from a ci flexographic printing press is exceptional, and we can help you model it. The key returns come from:
1. Drastic Waste Reduction: Superior ±0.10mm registration on thin films means minimal setup and running waste.
2. Higher-Margin Jobs: The ability to print flawlessly on flexible packaging and laminates unlocks premium jobs your competitors cannot take.
3. Automated Efficiency: Our gearless models offer rapid 10-minute changeovers, drastically cutting labor costs and maximizing productive uptime.

CI Flexo Printing Machines

Say Goodbye to Misregistration Waste and Costly Downtime With KETE CI Flexo Printing Machine

Struggling with Unstable Registration?

Guaranteed ±0.10mm Registration Lock

Forced to Choose Between Speed and Quality?

True 450m/min Production Speed

Wasting Hours on Job Changeovers?

Automated Setup & Rapid Changeover

Multiple Choices Central Impression Flexo Press (Gear Type / Gearless Type)

Compliance, Uptime, and Simplified Workflow: The KETE CI Flexo Printing Press Advantage

Streamline Production with Inline Finishing

Food-Grade & Eco-Friendly Compliance

Engineered for Long-Term Durability

Engineered for Your Substrate: Proven Quality on Any Material

रोल प्लास्टिक फिल्म मुद्रण

सांस लेने योग्य फिल्म मुद्रण

हेवी ड्यूटी फिल्म प्रिंटिंग

रोल एफएफएस फिल्म प्रिंटिंग

प्लास्टिक फिल्म मुद्रण

PP Woven Fabric Printing

पीपी बुना कपड़ा बैग मुद्रण

PP Woven Printing

गैर बुना कपड़ा मुद्रण

Laminated Film Printing

Laminated Film Printing

Lidding Foil Printing

एल्युमिनियम फॉयल प्रिंटिंग

Why Choose KETE as Your CI Flexo Printing Machine Manufacturer?

01

02

03

04

05

06

नंबर 1

Tailoring Your Press Around Your Business Goals

नं.2

Guaranteeing Press Quality with Our 5-Stage Protocol

नंबर 3

Expert On-Site Commissioning for Immediate Production

नं .4

Training for Operator Self-Sufficiency & Peak Performance

पाँच नंबर

Rapid-Response Global Support Structured for Your Uptime

24-Hour Remote Response

Local On-Site Support

Proactive Partnership

पाँच नंबर

Protecting Your Production with a Guaranteed Parts Inventory

Doctor Blades

एनिलॉक्स रोलर्स

Ink Pumps

Ink Mix Rollers

कोरोना उपचार

स्टेटिक एलिमिनेटर

Motors & Drivers

Web Guide Rollers & Sensors

General Replacement Parts

- About CI Flexo Press

What is a Central Impression Flexo Press?

CI Press vs. Stack vs. Inline: A Comparison

The Industries That Benefit From CI Flexo Printing

खाद्य और पेय

Pharmaceutical & Medical

Personal Care & Hygiene

Pet Food Packaging

High-End Paper Applications

Agricultural & Chemical (FFS)

सामान्य प्रश्न
